1658787-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
DDR3 / DDR2 / DDR Connectors
PDF
/
Inventory: 2187
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 15μin
Contact Finish Thickness 15.0μin 0.38μm
Technical
PCB Contact Row Spacing 0.075 mm
Memory Type DDR2 SDRAM
Connector Style DIMM
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000Ohm
Body Depth 1.443 inch
Housing Color Black
Operating Temperature (Min) -55°C
Operating Temperature (Max) 105°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.711 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 240
Pitch 1mm
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Number of Positions 240
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Guide, Board Lock, Latches
Published 2008
Packaging Tray
Physical
Housing Material Thermoplastic
Mounting Type Through Hole, 25° Angle
Mount Through Hole
Contact Material COPPER ALLOY
