1565918-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
CONN SKT SODIMM 200POS R/A SMD
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.344
≥1 USD $3.344
≥10 USD $2.98232
≥100 USD $2.96736
≥500 USD $2.936912
Inventory: 3587
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Stack Height 5.2mm
Contact Finish Thickness Flash
Length 71.5mm
Technical
Circuit Application Power
Contact Current Rating 500mA
Sealable No
Memory Type DDR2 SDRAM
Connector Style SODIMM
Max Current Rating 500mA
ELV Compliant
Row Spacing 6.1976 mm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Lead Pitch 600μm
Contact Finish Gold
Depth 26.5mm
Orientation Right Angle
Total Number of Contacts 200
Pitch 609.6μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Additional Feature LATCHED
Voltage - Rated 1.8V
Number of Rows 2
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 200
Connector Type Socket
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Latches
Published 2007
Packaging Tape & Reel (TR)
Physical
Housing Material Thermoplastic
Mounting Feature Reverse
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 25 Weeks
