1473149-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
DIMM Connectors .6MM 200D R/SM 1.8V DIMMSO DDR
PDF
/
Buying Options
Total Price: USD $4.04
Unit Price: USD $4.0392
≥1 USD $4.0392
≥10 USD $3.54288
≥100 USD $3.45004
≥500 USD $3.375794
≥1000 USD $3.26561
Inventory: 1194
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 5.2mm
Contact Finish Thickness Flash
Length 71.5mm
Height 6.23mm
Technical
Circuit Application Power
Contact Current Rating 500mA
Sealable No
Memory Type DDR2 SDRAM
Connector Style SODIMM
Polarization Key POLARIZED HOUSING
Max Current Rating 500mA
ELV Compliant
Body/Shell Style SOCKET
Row Spacing 6.1976 mm
Insulation Resistance 50000000Ohm
Contact Style BELLOWED TYPE
Rated Current (Signal) 0.5A
Housing Color Black
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 500mA
Depth 26.5mm
Orientation Right Angle
Total Number of Contacts 200
Pitch 609.6μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 1.8V
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 200
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Latches
Published 2007
Packaging Tray
Physical
Insulation Material Thermoplastic
Mounting Feature Normal, Standard - Top
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 25 Weeks
