177827-3
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
DIMM Connectors M3 SOCKET 15190
PDF
/
Inventory: 9497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 65.89mm
Technical
Durability 30 Cycles
Memory Type RAM
Polarization Key POLARIZED HOUSING
ELV Non-Compliant
Body/Shell Style SOCKET
Insulation Resistance 250MOhm
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Housing Color Natural
UL Flammability Code 94V-0
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Number of Contacts 72
Lead Pitch 1.27mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Number of Conductors ONE
Depth 29.58mm
Orientation Right Angle
Pitch 635μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature STAGGERED CONFIGURATION
Voltage - Rated 5V
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Connector Type CARD EDGE CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code no
JESD-609 Code e0
Physical
Insulation Material Polymer
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
