1612619-4
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Memory Card Connectors SEMI-HARD TRAY 200P DDR2 SODIMM SOCKET
PDF
/
Inventory: 3145
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Rated Current (Signal) 0.5A
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender FEMALE
Operating Temperature (Max) 85°C
PCB Contact Pattern STAGGERED
Number of Contacts 200
Number Of PCB Rows 2
Row Spacing - Mating 6.1976 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Depth 26.5mm
Orientation Straight
Pitch 609.6μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Voltage - Rated 1.8V
Number of Rows 2
Connector Type CARD EDGE CONNECTOR
Termination SMD/SMT
Pbfree Code yes
Memory Type DDR, SDRAM
Polarization Key POLARIZED KEY
ELV Compliant
Body/Shell Style SOCKET
Insulation Resistance 50000000Ohm
Contact Style BELLOWED TYPE
Physical
Housing Material Thermoplastic
Mount Surface Mount
Contact Plating Gold
Contact Material NOT SPECIFIED
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 8.001mm
Length 71.1mm
Height 8mm
