1746540-4
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Conn SO DIMM Socket SKT 200 POS 0.6mm Solder RA SMD Tray
PDF
/
Buying Options
Total Price: USD $2.44
Unit Price: USD $2.44199
≥1 USD $2.44199
≥10 USD $2.303761
≥100 USD $2.17336
≥500 USD $2.050339
≥1000 USD $1.934286
Inventory: 8463
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Housing Material Thermoplastic
Technical
Packaging Box
JESD-609 Code e4
Pbfree Code yes
Termination Solder
Connector Type CARD EDGE CONNECTOR
Max Operating Temperature 185°C
Min Operating Temperature -67°C
Number of Rows 2
Voltage - Rated 1.8V
Additional Feature LOW PROFILE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 609.6μm
Orientation Right Angle
Depth 26.55mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 5.588 mm
Number Of PCB Rows 2
Number of Contacts 200
PCB Contact Pattern RECTANGULAR
Body Breadth 0.157 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Contact Style BELLOWED TYPE
Insulation Resistance 50000000Ohm
Body/Shell Style SOCKET
Polarization Key POLARIZED HOUSING
Memory Type DDR, SDRAM
PCB Contact Row Spacing 7.5946 mm
Sealable No
Circuit Application Power
Contact Rating (Current) 500mA
Current Rating (Max) 500mA
Dimensions
Length 71.5mm
Plating Thickness FLASH inch
Stack Height 4.6mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
