87636-2002
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
CONN SKT DIMM 184POS PCB
PDF
/
Inventory: 8189
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.127 inch
Plating Thickness 15u inch
Technical
Insulator Color BLACK
Mating Contact Row Spacing 0.156 inch
Contact Finish Termination TIN (75) OVER NICKEL
Durability 25 Cycles
PCB Contact Row Spacing 0.075 mm
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
Body Depth 0.25 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -10°C
Contact Gender FEMALE
Body Breadth 0.29 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.55 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Total Number of Contacts 184
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (15) OVER NICKEL
Subcategory Headers and Edge Type Connectors
Additional Feature LATCHED
Number of Rows 2
Connector Type CARD EDGE CONNECTOR
JESD-609 Code e3
Physical
Mounting Option 2 LOCKING
Board Mounting Option SPLIT BOARD LOCK
Mounting Style STRAIGHT
Mounting Option 1 LATCH & EJECT
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Mounting Type BOARD
Contact Material PHOSPHOR BRONZE
