87609-0059
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
STAGGERED CONFIGURATION Inline Module Socket
PDF
/
Inventory: 6765
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.125 inch
Plating Thickness 15μin
Technical
Durability 25 Cycles
PCB Contact Row Spacing 0.063 mm
Dielectric Withstanding Voltage 500VAC V
Polarization Key RIGHT
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 40mOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
Operating Temperature (Min) -10°C
Contact Gender FEMALE
Body Breadth 0.548 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.551 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Total Number of Contacts 168
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature STAGGERED CONFIGURATION
Number of Rows 2
Number of Positions 168
Connector Type CARD EDGE CONNECTOR
ECCN Code EAR99
Physical
Insulation Material THERMOPLASTIC
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
