0879781021
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Conn DIMM Socket SKT 240 POS 1mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 5545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Technical
Standards MO-237
Memory Type DDR2 SDRAM
Connector Style DIMM
Body/Shell Style SOCKET
UL Flammability Code 94V-0
Contact Gender FEMALE
Number of Contacts 240
Contact Finish Gold
Current Rating 500mA
Orientation Straight
Pitch 1mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE, LATCHED, POLARIZED
Voltage - Rated 30V
Number of Rows 2
Min Operating Temperature -10°C
Max Operating Temperature 85°C
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Latches
JESD-609 Code e3
Series 87978
Packaging Tray
Physical
Weight 9.329998g
Housing Material Thermoplastic
Mounting Feature Normal, Standard - Top
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Brass, Bronze
Supply Chain
Factory Lead Time 16 Weeks
