0780790011
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Conn DDR3 DIMM Socket SKT 240 POS 2mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 6450
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Through Hole
Mounting Type Through Hole
Mounting Feature Normal, Standard - Top
Insulation Material Nylon
Technical
Packaging Tray
Series 78079
JESD-609 Code e3
Feature Board Lock, Latches
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Number of Rows 2
Additional Feature LATCHED, POLARIZED
Voltage - Rated DC 30V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Orientation Straight
Current Rating 1A
Contact Finish Gold
Voltage - Rated AC 30V
Number of Contacts 240
Contact Gender FEMALE
UL Flammability Code 94V-0
Body/Shell Style SOCKET
Connector Style DIMM
Memory Type DDR3 SDRAM
Standards MO-269
Dimensions
Length 148mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
