59355-052FSLF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MEMORY SOCKET, SO-DIMM, 200POS - More Details
PDF
/
Buying Options
Total Price: USD $78.01
Unit Price: USD $78.01305
≥1 USD $78.01305
≥10 USD $64.011
≥100 USD $62.0103
≥500 USD $60.0096
≥1000 USD $58.00985
Inventory: 2663
Minimum: 1
-
+
Technical Details
Technical
Number of Positions 200
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Number of Rows 2
Gender Female
Connector Type Socket
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Latches
Published 2008
Packaging Tray
Standards MO-224
Memory Type DDR SDRAM
Connector Style SODIMM
Row Spacing 6.2 mm
Insulation Resistance 100MOhm
Contact Resistance 30mOhm
Housing Color Black
Number of Contacts 200
Voltage - Rated AC 50V
Contact Finish Gold
Current Rating 300mA
Depth 25.2mm
Orientation Right Angle
Pitch 600μm
Voltage - Rated 50V
Physical
Housing Material Thermoplastic
Insulation Material Polymer
Mounting Feature Reverse
Mounting Type Surface Mount, 30° Angle
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 8 Weeks
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness Flash
Width 70.9mm
Length 72.2mm
