10129206-1012013LF
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
COMMERCIAL UL STAGGERED AU ON NI (Connector Style) Socket 0.22inch
PDF
/
Inventory: 6933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type BOARD
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Technical
Part Status Active
Connector Type CARD EDGE CONNECTOR
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Total Number of Contacts 288
Reach Compliance Code compliant
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 5.709 inch
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Body Breadth 0.22 inch
Body Depth 0.516 inch
Mating Contact Pitch 0.033 inch
Termination Type SOLDER
Contact Finish Termination TIN
Dimensions
Plating Thickness 30μin
Length - Termination 0.102 inch
