10124632-1050001LF

Amphenol ICC (FCI)
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description Inline Module Socket
PDF
/
Inventory: 8238
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length - Termination 0.116 inch
Plating Thickness 15μin

Technical

Insulator Color NATURAL
Contact Finish Termination Matte Tin (Sn)
Termination Type SOLDER
Mating Contact Pitch 0.033 inch
Body Depth 0.839 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.591 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code compliant
Terminal Pitch 1.7018mm
Total Number of Contacts 288
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Connector Type CARD EDGE CONNECTOR
Part Status Active
JESD-609 Code e3

Physical

Board Mounting Option SPLIT BOARD LOCK
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Mounting Type BOARD
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 9 Weeks
