10124632-0202007LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MO-309 RoHS Compliant COMMERCIAL UL DIMM Socket 0.253inch
PDF
/
Inventory: 3643
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material COPPER ALLOY
Mount Through Hole
Mounting Type Through Hole
Mounting Feature Normal, Standard - Top
Technical
Packaging Tray
Published 2015
JESD-609 Code e3
Feature Board Lock, Latches
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 288
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 288
Terminal Pitch 1.7018mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 5.591 inch
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Body Breadth 0.253 inch
Body Depth 0.57 inch
Contact Style BELLOWED TYPE
Mating Contact Pitch 0.033 inch
Termination Type SOLDER
Connector Style DIMM
Memory Type DDR4 SDRAM
Insulator Color BLUE
Standards MO-309
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 15μin
Length - Termination 0.102 inch
Compliance
RoHS Status RoHS Compliant
