10124632-0132003LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Inline Module Socket
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.662131
≥1 USD $1.662131
≥200 USD $0.643321
≥500 USD $0.621002
≥1000 USD $0.610499
Inventory: 2723
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.094 inch
Plating Thickness 30μin
Technical
Insulator Color BLUE
Contact Finish Termination Matte Tin (Sn)
Termination Type SOLDER
Mating Contact Pitch 0.033 inch
Contact Style BELLOWED TYPE
Body Depth 0.57 inch
Body Breadth 0.253 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.591 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 1.7018mm
Total Number of Contacts 288
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Connector Type CARD EDGE CONNECTOR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e3
Physical
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Mounting Type BOARD
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 9 Weeks
