10124632-0031401LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MO-309 RoHS Compliant COMMERCIAL UL DIMM Socket 0.57inch
PDF
/
Inventory: 6841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.094 inch
Plating Thickness 15μin
Contact Finish Thickness 15.0μin 0.38μm
Technical
Standards MO-309
Insulator Color BLACK
Memory Type DDR4 SDRAM
Connector Style DIMM
Contact Style BELLOWED TYPE
Body Depth 0.57 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.591 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 288
Pitch 850μm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Number of Positions 288
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Latches
JESD-609 Code e3
Published 2015
Packaging Tray
Physical
Mounting Feature Normal, Standard - Top
Mounting Type Through Hole
Mount Through Hole
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 9 Weeks
