1759066-1
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Accessories
Description
Memory Card Connectors Shielded Exp.Card Top Entry
PDF
/
Inventory: 5121
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Withdrawl Force-Min 4.448 N
Contact Pattern RECTANGULAR
Accessory Type Frame
Dielectric Withstanding Voltage 500VAC V
Body/Shell Style RECEPTACLE
Insulation Resistance 500000000Ohm
Contact Resistance 55mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.75A
Body Depth 2.829 inch
Operating Temperature (Min) -55°C
Body Breadth 0.236 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 26
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Orientation Right Angle
Pitch 1mm
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Connector Type PCMCIA CONNECTOR
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series III
Published 2006
Packaging Bulk
Physical
Insulation Material THERMOPLASTIC
Mount Surface Mount
Contact Material COPPER ALLOY
