AT25DQ161-SH-B
RoHS
/
Package 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
HARDWARE/SOFTWARE Synchronous Obsolete SPI FLASH Memory -40C~85C TC 2.7V 16Mb 19mA
PDF
/
Inventory: 3289
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 5.4mm
Length 5.35mm
Height 1.91mm
Technical
Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 20
Endurance 100000 Write/Erase Cycles
Serial Bus Type SPI
Programming Voltage 2.7V
Word Size 8b
Sync/Async Synchronous
Standby Current-Max 0.00001A
Density 16 Mb
Address Bus Width 21b
Write Cycle Time - Word, Page 7μs, 3ms
Data Bus Width 8b
Memory Interface SPI
Memory Format FLASH
Access Time 5 ns
Clock Frequency 100MHz
Memory Type Non-Volatile
Nominal Supply Current 19mA
Memory Size 16Mb 2M x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TC
Physical
Number of Pins 8
Package / Case 8-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
