8073
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Magnetic Wire
Description
Hook-up Wire 14AWG 1C 80FT 1 POUND SPOOL
PDF
/
Buying Options
Total Price: USD $571.99
Unit Price: USD $571.9912
≥1 USD $571.9912
Inventory: 93
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Insulation Material Polyester
Weight 453.59237g
Conductor Material Copper, Annealed Bare
Jacket (Insulation) Material Polyamide
Technical
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Max Operating Temperature 200°C
Voltage - Rated 4.85kV
Voltage - Rated DC 600V
Number of Conductors 1
Wire Gauge 14 AWG
Max Current Rating 5.9A
Connector Support Type WIRE AND CABLE
Wire/Cable Type Hook-Up
Wire/Cable Gauge 14 AWG
Jacket (Insulation) Diameter 0.068 (1.73mm)
Wire/Cable Diameter 1.73 mm
Outside Diameter 1.73 mm
Dimensions
Length 24.384m
Length - Approximate 80.0' 24m
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings MW 35-C HY
