OMH3075
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH TO92-3
PDF
/
Buying Options
Total Price: USD $38.82
Unit Price: USD $38.823766
≥1 USD $38.823766
≥200 USD $15.024828
≥500 USD $14.497042
≥1000 USD $14.235775
Inventory: 999
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Supplier Device Package TO-92-3
Technical
Operating Temperature -55°C~125°C TA
Packaging Bulk
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Technology Hall Effect
Voltage - Supply 4.5V~24V
Function Latch
Current - Supply (Max) 11mA
Output Type Open Collector
Max Output Current 25mA
Polarity South Pole
Polarization South Pole
Current - Output (Max) 25mA
Max Supply Current 11mA
Logic Function Latch
Sensing Method Hall Effect
Test Condition -55°C ~ 125°C
Sensing Range 27.5mT Trip, -27.5mT Release
Compliance
RoHS Status RoHS Compliant
