OHS3140U
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $5.2
Unit Price: USD $5.2008
≥1 USD $5.2008
≥10 USD $4.852144
Inventory: 996
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Supplier Device Package TO-92-3
Technical
Operating Temperature -40°C~125°C TA
Packaging Bulk
Published 2007
Series OHS3100
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Hall Effect Sensor
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 4.5V~24V
Current Rating 7mA
Function Unipolar Switch
Current - Supply (Max) 7mA
Output Type Open Collector
Max Output Current 25mA
Operating Supply Voltage 12V
Polarity South Pole
Max Supply Voltage 24V
Min Supply Voltage 4.5V
Polarization South Pole
Current - Output (Max) 25mA
Nominal Supply Current 4mA
Output Current 21mA
Max Supply Current 7mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range 27mT Trip, 2.5mT Release
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
