OHS3130U image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Inventory: 6050
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Sensing Range 20mT Trip, -20mT Release
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 7mA
Current - Output (Max) 25mA
Polarization South Pole
Polarity South Pole
Operating Supply Voltage 12V
Max Output Current 25mA
Output Type Open Collector
Current - Supply (Max) 7mA
Function Unipolar Switch
Voltage - Supply 4.5V~24V
Technology Hall Effect
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Hall Effect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series OHS3100
Published 2007
Packaging Bulk
Operating Temperature -40°C~125°C TA

Physical

Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole

Supply Chain

Factory Lead Time 10 Weeks
