OHS3120U
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $4.62
Unit Price: USD $4.622721
≥1 USD $4.622721
≥200 USD $1.789483
≥500 USD $1.726464
≥1000 USD $1.694954
Inventory: 1278
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Supplier Device Package TO-92-3
Technical
Operating Temperature -40°C~125°C TA
Packaging Bulk
Series OHS3100
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Hall Effect, Unipolar Switch
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 4.5V~24V
Function Unipolar Switch
Current - Supply (Max) 7mA
Output Type Open Collector
Max Output Current 25mA
Polarity South Pole
Max Supply Voltage 24V
Min Supply Voltage 4.5V
Operating Supply Current 7mA
Polarization South Pole
Current - Output (Max) 25mA
Nominal Supply Current 4mA
Output Current 25mA
Max Supply Current 7mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range 45mT Trip, 2.5mT Release
Compliance
RoHS Status RoHS Compliant
