OHS3119U
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Inventory: 956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Sensing Range 57.5mT Trip, 2.5mT Release
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 7mA
Nominal Supply Current 4mA
Current - Output (Max) 25mA
Polarization South Pole
Operating Supply Current 7mA
Min Supply Voltage 4.5V
Max Supply Voltage 24V
Polarity South Pole
Max Output Current 25mA
Output Type Open Collector
Current - Supply (Max) 7mA
Function Unipolar Switch
Voltage - Supply 4.5V~24V
Technology Hall Effect
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Hall Effect, Unipolar Switch
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series OHS3100
Packaging Bulk
Operating Temperature -40°C~125°C TA
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
