OHN3140U
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $10.97
Unit Price: USD $10.973218
≥1 USD $10.973218
≥200 USD $4.378522
≥500 USD $4.23279
≥1000 USD $4.16058
Inventory: 1412
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Sensing Range 26mT Trip, 2.5mT Release
Test Condition -20°C ~ 85°C
Sensing Method Hall Effect
Max Supply Current 7mA
Output Current 21mA
Nominal Supply Current 4mA
Current - Output (Max) 25mA
Polarization South Pole
Operating Supply Current 7mA
Min Supply Voltage 4.5V
Max Supply Voltage 24V
Polarity South Pole
Max Output Current 25mA
Output Type Open Collector
Current - Supply (Max) 7mA
Function Unipolar Switch
Voltage - Supply 4.5V~24V
Technology Hall Effect
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Type Hall Effect, Unipolar Switch
Termination Connector
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series OHN3100
Published 2007
Packaging Bulk
Operating Temperature -20°C~85°C TA
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
