OHN3131U
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Inventory: 5572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Hall Effect
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Technology Hall Effect
Voltage - Supply 4.5V~24V
Function Unipolar Switch
Current - Supply (Max) 7mA
Output Type Open Collector
Max Output Current 25mA
Polarity South Pole
Max Supply Voltage 24V
Min Supply Voltage 4.5V
Polarization South Pole
Current - Output (Max) 25mA
Nominal Supply Current 4mA
Output Current 25mA
Max Supply Current 7mA
Sensing Method Hall Effect
Test Condition -20°C ~ 85°C
Sensing Range 9.5mT Trip, -5.9mT Release
Series OHN3100
Published 2007
Packaging Bulk
Operating Temperature -20°C~85°C TA
Compliance
RoHS Status RoHS Compliant
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
