OHN3120U image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.0248
≥1 USD $5.0248
≥10 USD $4.610144
Inventory: 221
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Technical

Sensing Range 42.5mT Trip, 5mT Release
Test Condition -20°C ~ 85°C
Sensing Method Hall Effect
Max Supply Current 7mA
Output Current 25mA
Nominal Supply Current 9mA
Current - Output (Max) 25mA
Polarization South Pole
Min Supply Voltage 4.5V
Max Supply Voltage 24V
Polarity South Pole
Operating Supply Voltage 12V
Max Output Current 25mA
Output Type Open Collector
Output Voltage 25V
Current - Supply (Max) 7mA
Function Unipolar Switch
Voltage - Supply 4.5V~24V
Technology Hall Effect
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Type Hall Effect Sensor
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series OHN3100
Published 2007
Packaging Bulk
Operating Temperature -20°C~85°C TA

Physical

Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
