OHN3075U image
Favorite
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH TO92-3
PDF
/
Inventory: 2208
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Sensing Range 25mT Trip, -25mT Release
Test Condition 25°C
Sensing Method Hall Effect
Logic Function Latch
Max Supply Current 7mA
Output Current 25mA
Nominal Supply Current 4mA
Current - Output (Max) 25mA
Polarization South Pole
Min Supply Voltage 4.5V
Max Supply Voltage 24V
Polarity South Pole
Max Output Current 25mA
Output Type Open Collector
Current - Supply (Max) 7mA
Function Latch
Voltage - Supply 4.5V~24V
Technology Hall Effect
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Type Hall Effect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series OHN3000
Published 2007
Packaging Bulk
Operating Temperature -20°C~85°C TA

Physical

Supplier Device Package TO-92-3
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
