PDRV5013FAEDBZRQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH SOT23-3
PDF
/
Inventory: 7011
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1.005mm
Technical
Magnetic Field Range-Max 2.9 mT
Output Interface Type 2-WIRE INTERFACE
Magnetic Field Range-Min -2.9 mT
Output Range 0-38V
Hysteresis 2.5 mT
Sensing Range 2.9mT Trip, -2.9mT Release
Housing PLASTIC
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 2.7mA
Polarization South Pole
Termination Type SOLDER
Polarity South Pole
Max Output Current 30mA
Output Type Open Drain
Body Breadth 1.3 mm
Body Length or Diameter 2.92mm
Current - Supply (Max) 2.7mA Typ
Function Latch
Base Part Number DRV5013
Voltage - Supply 2.7V~38V
Technology Hall Effect
Additional Feature IT HAS SENSITIVITY 1.3 MT, SHORT CIRCUIT PROTECTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Temperature Compensated
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
