DRV5033AJQLPGM
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.49192
≥100 USD $0.423456
≥500 USD $0.40832
≥1000 USD $0.347864
≥3000 USD $0.302474
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.52mm
Width 3.15mm
Length 4mm
Height 5.05mm
Technical
Magnetic Field Range-Max 12 mT
Magnetic Field Range-Min 1 mT
Sensing Range ±12mT Trip, ±1mT Release
Housing PLASTIC
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 2.7mA
Output Current 30mA
Polarization North Pole, South Pole
Operating Supply Voltage 38V
Max Output Current 30mA
Output Type Open Drain
Current - Supply (Max) 2.7mA Typ
Function Omnipolar Switch
Base Part Number DRV5033
Voltage - Supply 2.7V~38V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Type Omnipolar Switch
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Packaging Tape & Box (TB)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 Short Body
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
