DRV5033AJELPGQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-92
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOL
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.1
≥1 USD $1.1
≥10 USD $0.82632
≥100 USD $0.661056
≥500 USD $0.60588
≥1000 USD $0.50952
≥3000 USD $0.454432
Inventory: 1099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Package / Case TO-92
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Omnipolar Switch
Terminal Finish Matte Tin (Sn)
Additional Feature AEC-Q100, SHORT CIRCUIT PROTECTION, REVERSE SUPPLY PROTECTION
Technology Hall Effect
Voltage - Supply 2.7V~38V
Base Part Number DRV5033
Function Omnipolar Switch
Current - Supply (Max) 2.7mA Typ
Output Type Open Drain
Polarization North Pole, South Pole
Current - Output (Max) 30mA
Test Condition -40°C ~ 150°C
Housing PLASTIC
Sensing Range ±12mT Trip, ±1mT Release
Magnetic Field Range-Min 1 mT
Magnetic Field Range-Max 12 mT
Dimensions
Height 5.05mm
Length 4mm
Width 3.15mm
Thickness 1.52mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
