DRV5032AJDBZR
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
LP HALL 32AJDBZR/DNCR
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.78274
≥1 USD $0.78274
≥10 USD $0.73843
≥100 USD $0.69663
≥500 USD $0.6572
≥1000 USD $0.62
≥3000 USD $0.58491
Inventory: 12924
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Input Mode UNIPOLAR
Magnetic Field Range-Max 4.8 mT
Magnetic Field Range-Min -0.5 mT
Hysteresis 1.5 mT
Sensing Range ±3mT Trip, ±1.5mT Release
Test Condition 25°C
Output Polarity COMPLEMENTARY
Current - Output (Max) 5mA
Polarization North Pole, South Pole
Termination Type SOLDER
Output Type Open Drain
Current - Supply (Max) 3.5μA
Function Omnipolar Switch
Base Part Number DRV5032
Voltage - Supply 1.65V~5.5V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
