DRV5023BIELPGMQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR TO92-3
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.026
≥1 USD $1.026
≥10 USD $0.8417
≥100 USD $0.81605
≥500 USD $0.78945
≥1000 USD $0.76285
Inventory: 109
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Short Body
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Box (TB)
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Unipolar Switch
Terminal Finish Matte Tin (Sn)
Additional Feature AEC-Q100, SHORT CIRCUIT PROTECTION, REVERSE SUPPLY PROTECTION
Technology Hall Effect
Voltage - Supply 2.7V~38V
Base Part Number DRV5023
Function Unipolar Switch
Current - Supply (Max) 2.7mA Typ
Output Type Open Drain
Max Output Current 30mA
Polarity South Pole
Polarization South Pole
Max Supply Current 2.7mA
Sensing Method Hall Effect
Test Condition -40°C ~ 150°C
Housing PLASTIC
Sensing Range 24mT Trip, 3mT Release
Hysteresis 8.5 mT
Magnetic Field Range-Max 24 mT
Dimensions
Height 5.05mm
Length 4mm
Width 3.15mm
Thickness 1.52mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
