DRV5013FAQDBZR
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
TEXAS INSTRUMENTS DRV5013FAQDBZR Hall Effect Switch, Bipolar, 0.0013 T, -0.0013 T, 2.5 V, 38 V, SOT-23New
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.462
≥100 USD $0.398112
≥500 USD $0.384032
≥1000 USD $0.327096
≥3000 USD $0.284416
Inventory: 8852
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology Hall Effect
Voltage - Supply 2.5V~38V
Base Part Number DRV5013
Function Latch
Current - Supply (Max) 3.5mA
Output Type Open Drain
Termination Type SOLDER
Polarization North Pole, South Pole
Current - Output (Max) 30mA
Test Condition -40°C ~ 125°C
Housing PLASTIC
Sensing Range 1.3mT Trip, -1.3mT Release
Hysteresis 2.6 mT
Dimensions
Height 1.22mm
Length 2.92mm
Width 1.3mm
Thickness 1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
