DRV5013BCEDBZTQ1
RoHS
RoHS compliant
RoHS compliantPackage SOT-23
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.04016
≥100 USD $0.831776
≥500 USD $0.762608
Inventory: 1124
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Magnetic Field Range-Max 18 mT
Output Interface Type 2-WIRE INTERFACE
Magnetic Field Range-Min -18 mT
Hysteresis 24 mT
Sensing Range 18mT Trip, -18mT Release
Test Condition -40°C ~ 150°C
Current - Output (Max) 30mA
Polarization South Pole
Termination Type SOLDER
Output Type Open Drain
Current - Supply (Max) 2.7mA Typ
Function Latch
Base Part Number DRV5013
Voltage - Supply 2.7V~38V
Technology Hall Effect
Additional Feature AEC-Q100, SHORT CIRCUIT PROTECTION, REVERSE SUPPLY PROTECTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case SOT-23
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
