DRV5013AGQLPG
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
TEXAS INSTRUMENTS DRV5013AGQLPGHall Effect Sensor, Latching, 30 mA, TO-226AA, 3 Pins, 2.5 V, 38 V
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.60192
≥100 USD $0.481184
≥500 USD $0.441232
≥1000 USD $0.371043
≥3000 USD $0.3531
Inventory: 5193
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.52mm
Width 3.15mm
Length 4mm
Height 5.05mm
Technical
Input Mode BIPOLAR
Magnetic Field Range-Max 9 mT
Magnetic Field Range-Min -9 mT
Hysteresis 12 mT
Sensing Range 9mT Trip, -9mT Release
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 2.7mA
Output Current 30mA
Polarization South Pole
Termination Type SOLDER
Polarity South Pole
Max Output Current 30mA
Output Type Open Drain
Current - Supply (Max) 2.7mA Typ
Function Latch
Base Part Number DRV5013
Voltage - Supply 2.7V~38V
Technology Hall Effect
Additional Feature SHORT CIRCUIT PROTECTION
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Packaging Bulk
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 Short Body
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
