DRV5013ADELPGMQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH TO92-3
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
≥10 USD $0.54912
≥100 USD $0.472736
≥500 USD $0.456016
≥1000 USD $0.388432
≥3000 USD $0.337744
Inventory: 1088
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Short Body
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Box (TB)
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature AEC-Q100, SHORT CIRCUIT PROTECTION, REVERSE SUPPLY PROTECTION
Technology Hall Effect
Voltage - Supply 2.7V~38V
Base Part Number DRV5013
Function Latch
Current - Supply (Max) 2.7mA Typ
Output Type Open Drain
Max Output Current 30mA
Polarity South Pole
Termination Type SOLDER
Polarization South Pole
Max Supply Current 2.7mA
Sensing Method Hall Effect
Test Condition -40°C ~ 150°C
Sensing Range 5mT Trip, -5mT Release
Hysteresis 5.4 mT
Magnetic Field Range-Min -5 mT
Output Interface Type 2-WIRE INTERFACE
Magnetic Field Range-Max 5 mT
Dimensions
Height 5.05mm
Length 4mm
Width 3.15mm
Thickness 1.52mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
