DRV5011ADDMRR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 4-XFDFN Exposed Pad
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description LP HALL 11ADDMR
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.3256
≥100 USD $0.285824
≥500 USD $0.2684
≥1000 USD $0.2288
≥3000 USD $0.189182
Inventory: 1493
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Mounting Type Surface Mount
Package / Case 4-XFDFN Exposed Pad
Surface Mount YES
Number of Pins 4

Technical

Operating Temperature -40°C~135°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature IT HAVE SENSITIVITY OF PLUS OR MINUS 2 MT
Technology Hall Effect
Voltage - Supply 2.5V~5.5V
Base Part Number DRV5011
Function Latch
Current - Supply (Max) 3mA
Output Type Push-Pull
Termination Type SOLDER
Polarization North Pole, South Pole
Current - Output (Max) 30mA
Test Condition -40°C ~ 150°C
Housing PLASTIC
Sensing Range ±0.6mT Trip, ±3.8mT Release
Output Range -5-20mA
Magnetic Field Range-Min -3.8 mT
Magnetic Field Range-Max 3.8 mT

Dimensions

Height 400μm
Length 1.4mm
Width 1.1mm
Thickness 400μm

Compliance

RoHS Status ROHS3 Compliant
