DRV5011ADDBZT
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
DRV5011ADDBZT
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.0648
≥1 USD $1.0648
≥10 USD $0.79728
≥100 USD $0.637824
Inventory: 5541
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Output Range -5-20mA
Hysteresis 4 mT
Sensing Range ±0.6mT Trip, ±3.8mT Release
Housing PLASTIC
Test Condition -40°C ~ 150°C
Current - Output (Max) 30mA
Polarization North Pole, South Pole
Termination Type SOLDER
Output Type Push-Pull
Current - Supply (Max) 3mA
Function Latch
Base Part Number DRV5011
Voltage - Supply 2.5V~5.5V
Technology Hall Effect
Additional Feature IT HAVE SENSITIVITY OF PLUS OR MINUS 2 MT
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~135°C TA
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
