HAL548 SF-E

TDK-Micronas GmbH
RoHS
RoHS RoHS compliant
Package TO-243AA, Variant
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description SOT-89B
PDF
/
Inventory: 8550
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Body Height 1.21mm

Technical

Magnetic Field Range-Max 24 mT
Magnetic Field Range-Min 6 mT
Hysteresis 6 mT
Housing PLASTIC
Current - Output (Max) 20mA
Termination Type SOLDER
Output Type Open Drain
Body Breadth 2.55 mm
Body Length or Diameter 4.55mm
Current - Supply (Max) 5.2mA
Reach Compliance Code compliant
Voltage - Supply 4.3V~24V
Technology Hall Effect
Additional Feature REVERSE VOLTAGE PROTECTION
Terminal Finish Matte Tin (Sn)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Series HAL? 54x
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C TJ

Physical

Surface Mount YES
Package / Case TO-243AA, Variant
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 32 Weeks
