HAL502SF-A

TDK-Micronas GmbH
RoHS
RoHS RoHS compliant
Package TO-243AA, Variant
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH SOT89B-1
PDF
/
Buying Options
Total Price: USD $13.96
Unit Price: USD $13.9612
≥1 USD $13.9612
≥10 USD $11.4551
≥100 USD $11.0979
≥500 USD $10.73975
≥1000 USD $10.3816
Inventory: 9849
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mounting Type Surface Mount
Package / Case TO-243AA, Variant
Supplier Device Package SOT-89B-1

Technical

Operating Temperature -40°C~170°C TJ
Packaging Tape & Reel (TR)
Published 2010
Series HAL? 5xy
Feature Temperature Compensated
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 140°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 3.8V~24V
Function Latch
Current - Supply (Max) 4.2mA
Output Type Open Drain
Max Output Current 20mA
Polarity South Pole
Polarization South Pole
Current - Output (Max) 20mA
Max Supply Current 4.2mA
Logic Function Latch
Sensing Method Hall Effect
Test Condition 25°C
Sensing Range 4.5mT Trip, -4.5mT Release

Compliance

RoHS Status RoHS Compliant
