BU52040HFV-TR
RoHS
RoHS compliant
RoHS compliantPackage SOT-665
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH HVSOF5
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.5256
≥1 USD $2.5256
≥10 USD $2.05832
≥100 USD $1.67024
≥500 USD $1.553552
≥1000 USD $1.475936
≥3000 USD $1.242894
Inventory: 1868
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case SOT-665
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
Type Bipolar Switch
Additional Feature CMOS COMPATIBLE
Subcategory Other Sensors
Max Power Dissipation 536mW
Technology Hall Effect
Voltage - Supply 1.65V~3.3V
Current Rating 200μA
Function Latch
Body Length or Diameter 1.6mm
Body Breadth 1.2 mm
Output Type Push-Pull
Max Output Current 500μA
Polarity South Pole
Power Supplies 1.8V
Polarization South Pole
Nominal Supply Current 200μA
Power Dissipation 536mW
Output Current 500μA
Max Supply Current 300μA
Sensing Method Hall Effect
Test Condition 25°C
Sensing Range 5mT Trip, -5mT Release
Hysteresis 6 mT
Output Range 0.20-1.60V
Dimensions
Body Height 0.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
