BU52025G-TR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR 5SSOP
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.6016
≥1 USD $1.6016
≥10 USD $1.20032
≥100 USD $0.959904
≥500 USD $0.879912
≥1000 USD $0.739922
≥3000 USD $0.65993
Inventory: 1159
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
Type Omnipolar Switch
Additional Feature SEATED HEIGHT-MAX
Subcategory Other Sensors
Max Power Dissipation 540mW
Technology Hall Effect
Voltage - Supply 2.4V~3.6V
Function Omnipolar Switch
Body Length or Diameter 2.9mm
Body Breadth 1.6 mm
Output Voltage 3.6V
Output Type Push-Pull
Max Output Current 1mA
Operating Supply Voltage 3V
Power Supplies 3V
Polarization North Pole, South Pole
Nominal Supply Current 8μA
Power Dissipation 540mW
Output Current 1mA
Max Supply Current 12μA
Output Polarity INVERTING
Sensing Method Hall Effect
Test Condition 25°C
Housing PLASTIC
Sensing Range ±5.5mT Trip, ±0.8mT Release
Hysteresis 0.8 mT
Output Range 0.40-2.60V
Magnetic Field Range-Min 0.8 mT
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
