BU52015GUL-E2
RoHS
RoHS compliant
RoHS compliantPackage 4-UFBGA, CSPBGA
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SW OMNIPOLAR 4-VCSP50L1
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 18003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 0.55mm
Technical
Magnetic Field Range-Max 5 mT
Magnetic Field Range-Min 0.6 mT
Output Range 0.20-1.60V
Hysteresis 0.9 mT
Sensing Range ±5mT Trip, ±0.6mT Release
Housing PLASTIC
Test Condition 25°C
Sensing Method Hall Effect
Output Polarity INVERTING
Max Supply Current 8μA
Output Current 500μA
Power Dissipation 420mW
Nominal Supply Current 5μA
Polarization North Pole, South Pole
Power Supplies 1.8V
Operating Supply Voltage 2.5V
Max Output Current 500μA
Output Type Push-Pull
Body Breadth 1.1 mm
Body Length or Diameter 1.1mm
Function Omnipolar Switch
Voltage - Supply 1.65V~3.3V
Technology Hall Effect
Max Power Dissipation 420mW
Subcategory Other Sensors
Additional Feature DUAL OUTPUT, SEATED HEIGHT-MAX
Type Omnipolar Switch
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 4
Package / Case 4-UFBGA, CSPBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Factory Lead Time 10 Weeks
