BU52014HFV-TR
RoHS
RoHS compliant
RoHS compliantPackage SOT-665
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR HVSOF5
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
≥1000 USD $0.7163
Inventory: 24783
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-665
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
Type Omnipolar Switch
Additional Feature CMOS OUTPUT, DUAL OUTPUT
Subcategory Other Sensors
Max Power Dissipation 536mW
Technology Hall Effect
Voltage - Supply 1.65V~3.3V
Current Rating 5μA
Function Omnipolar Switch
Body Length or Diameter 1.6mm
Body Breadth 1.2 mm
Output Type Push-Pull
Max Output Current 500μA
Operating Supply Voltage 1.8V
Polarization North Pole, South Pole
Nominal Supply Current 5μA
Power Dissipation 536mW
Output Current 500μA
Max Supply Current 8μA
Output Polarity COMPLEMENTARY
Sensing Method Hall Effect
Test Condition 25°C
Sensing Range ±5.5mT Trip, ±0.6mT Release
Hysteresis 0.9 mT
Output Range 0.20-1.60V
Magnetic Field Range-Min 0.6 mT
Dimensions
Body Height 0.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
