BU52004GUL-E2
RoHS
RoHS compliant
RoHS compliantPackage 4-UFBGA, CSPBGA
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SW OMNIPOLAR 4-VCSP50L1
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 5004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 0.55mm
Technical
Magnetic Field Range-Max 5.5 mT
Magnetic Field Range-Min 0.8 mT
Hysteresis 0.8 mT
Sensing Range ±5.5mT Trip, ±0.8mT Release
Test Condition 25°C
Sensing Method Hall Effect
Output Polarity INVERTING
Max Supply Current 12μA
Output Current 1mA
Power Dissipation 420mW
Nominal Supply Current 8μA
Polarization North Pole, South Pole
Power Supplies 3V
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 1.1 mm
Body Length or Diameter 1.1mm
Function Omnipolar Switch
Voltage - Supply 2.4V~3.3V
Technology Hall Effect
Max Power Dissipation 420mW
Subcategory Other Sensors
Additional Feature CMOS OUTPUT, DUAL OUTPUT
Type Omnipolar Switch
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 4
Package / Case 4-UFBGA, CSPBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Factory Lead Time 10 Weeks
