DN6849S
RoHS
/
Package 4-SMD, Gull Wing
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH BIPOLAR 4ESOP
PDF
/
Inventory: 3529
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 2mm
Technical
Sensing Range -17mT Trip, 17.5mT Release
Test Condition 25°C
Sensing Method Hall Effect
Max Supply Current 6mA
Polarization North Pole
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 16V
Polarity North Pole
Max Output Current 10μA
Output Type Open Collector
Qualification Status Not Qualified
Current - Supply (Max) 6mA
Function Bipolar Switch
JESD-30 Code S-PDSO-G4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.6mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.5V~16V
Technology Hall Effect
HTS Code 8542.39.00.01
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Temperature Compensated
Published 2002
Packaging Bulk
Operating Temperature -40°C~100°C TA
Physical
Surface Mount YES
Package / Case 4-SMD, Gull Wing
Mounting Type Surface Mount
