AN48846B-NL
RoHS
/
Package 6-SMD (5 Leads), Flat Lead
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNET SWITCH BIPOLAR SMINI-5DE
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 24001
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (5 Leads), Flat Lead
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series AN488xx
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 5
Type Hall Effect Sensor
Subcategory Other Sensors/Transducers
Technology Hall Effect
Voltage - Supply 1.65V~3.6V
Function Bipolar Switch
Current - Supply (Max) 65μA
Output Voltage 300mV
Output Type Push-Pull
Max Output Current 2mA
Operating Supply Voltage 1.8V
Polarity South Pole
Polarization South Pole
Nominal Supply Current 55μA
Max Supply Current 65μA
Sensing Method Hall Effect
Test Condition 25°C
Sensing Range 4mT Trip, -4mT Release
Magnetic Field Range-Min -4 mT
Magnetic Field Range-Max 4 mT
Dimensions
Height 800μm
Length 2mm
Width 1.7mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
