AD604-00E
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Tube AD Open Collector Hall Effect Digital Omnipolar Switch 20mA 4.5V~30V 125C ±2.5mT Trip ±1.1mT Release
PDF
/
Buying Options
Total Price: USD $4.68
Unit Price: USD $4.683114
≥1 USD $4.683114
≥200 USD $1.86957
≥500 USD $1.80655
≥1000 USD $1.775041
Inventory: 5241
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Supplier Device Package 8-MSOP
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2005
Series AD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 4.5V~30V
Function Omnipolar Switch
Current - Supply (Max) 4.5mA
Output Type Open Collector
Max Output Current 20mA
Polarization North Pole, South Pole
Current - Output (Max) 20mA
Max Supply Current 4.5mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range ±2.5mT Trip, ±1.1mT Release
Compliance
RoHS Status ROHS3 Compliant
