AD320-02E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Tube AD Open Collector Hall Effect Digital Omnipolar Switch 4.5mA 4.5V~30V -40C~125C TA ±3.4mT Trip ±1.4mT Release
PDF
/
Inventory: 4131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2005
Series AD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology Hall Effect
Voltage - Supply 4.5V~30V
Function Omnipolar Switch
Current - Supply (Max) 4.5mA
Output Type Open Collector
Max Output Current 20mA
Polarization North Pole, South Pole
Max Supply Current 4.5mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range ±3.4mT Trip, ±1.4mT Release
Compliance
RoHS Status ROHS3 Compliant
